4Hawks Raptor SR for DJI RC Plus (I3, M30, M350)

4Hawks Raptor SR for DJI RC Plus (I3, M30, M350) Long range extension & Maximize performance, no internal modifications needed

Features:
• Maximize performance
• Concurrent dual band 2.4 & 5GHz
• No modification to the drone itself
• Long range extension without external boosters
• Design does not contain any removable parts
• Complete solution

Compatibility:
• DJI RC Plus for Inspire 3
• DJI RC Plus for M30 Series
• DJI RC Plus for M300/350

Specification
Electrical & mechanical parameters of Raptor renge extender.
Frequencies:
Port 1: 2.40 - 2.50 GHz & 5.00 - 5.80 GHz
Port 2: 2.40 - 2.50 GHz & 5.00 - 5.80 GHz
Gain:
Port 1: 8 dBi (+/- 1 dBi) & 10 dBi (+/- 1 dBi)
Port 2: 8 dBi (+/- 1 dBi) & 10 dBi (+/- 1 dBi)
VSWR:
Port 1: < 1.50 (max. < 2.15)
Port 2: < 1.50 (max. < 2.15)
Beamwidth:
Port 1: 90°/65° & 55°/55°
Port 2: 90°/65° & 55°/55°
Polarization:
Port 1: Vertical
Port 2: Vertical
Impedance:
Port 1: 50 Ω
Port 2: 50 Ω
Material Antenna: Samsung ABS, polyurethane, aluminum, Stainless steel, Nylon, PTFE PCB
Mounting: Stainless steel + paint
Weight: 180g (110g Antenna + 70g Mounting)
Dimensions:
16.1 x 9.1 x 1.7 cm
6.34 x 3.60 x 0.67 inch
Connection:
Port 1: RP-SMA female
Port 2: RP-SMA female
Tilt adjustment: 5 tilt positions, OnClick system
