FeiyuTech G4Plus 3-Axis Premium Smartphone Gimbal
Product Highlights
• 3-Axis Motorized Gimbal
• Supports Phones Up to iPhone 6 Plus
• Fixed Axes and Pan/Tilt Following Modes
• 320° Pan/Tilt Rotation
• 100° Roll Rotation
• Single-Button Operation
• Battery Level Indicator Light
• Optional Gimbal Remote Control
• Four Batteries and Charger Included
The Feiyu G4 Plus 3-Axis Handheld Gimbal allows you to capture stabilized, free-floating shots with your smartphone, with support for larger models such as the iPhone 6 Plus and Samsung Note 5.. It is held and operated using a single hand and features four different operating modes for increased creative possibilities. You can choose to lock the camera in place along all three axes (pan, tilt, and roll), or select modes where the camera will smoothly follow as you pan and tilt the handle. Switching between modes is done using a single LED push-button on the handle, which flashes to indicate the mode selected.
The G4 Plus is designed for one-handed operation and features a design that hides all wires, resulting is a cleaner and sleeker look. To help balance the gimbal when using larger sized smartphones, two counterweights are included. It is powered using two rechargeable 900mAh batteries, which slot into the handle. A battery indicator light on the device lets you know when it's time to recharge the batteries using the included charger.
Key Features
• Five modes with single button operation
• LED battery level indicator light
• Handle threaded to accept optional extension pole
• Four batteries and charger included
• Optional Gimbal Remote Control
Modes
• Pan Following Mode: Locks tilt and roll axes. Camera smoothly pans to follow the direction of the handle
• Tilt and Pan Following Mode: Locks roll axis. Camera smoothly follows the pan and tilt motion of the handle
• All Axis Lock Mode: Locks the pan, tilt, and roll axes of the camera in the position it is in when mode is activated
• Inverted Mode: Allows you to turn the gimbal upside-down. This mode is an inverted version of the Pan Following Mode
• Standby Mode: The gimbal remains on but the motor is shut down
Rotation Angles
• Pan: 320°
• Tilt: 320°
• Roll: 100°
Specifications
• Compatibility Phones up to Apple iPhone 6 Plus / Samsung Note 5
• Motor 2804F
• Pan Angle -160° (left) to +160° (right) (held vertically)
• -50° (left) to +50° (right) (held horizontally)
• Tilt Angle -160° to +160° (held vertically)
• Roll Angle -50° to +50°
• Panning Following Rate 3°/s to 150°/s
• Tilt Following Rate 2°/s to 75°/s
• Motion Attitude Tracking Accuracy Minimum: 0.1°
• Standard: 0.2°
• Maximum: 0.5°
• (Motor overload <2G)
• Static Attitude Tracking Accuracy Minimum: 0.01°
• Standard: 0.02°
• Maximum: 0.05°
• (Gimbal in static mode)
• Start-Up Time 2.5 seconds
• Battery Type 2 x 18350 type, 900 mAh batteries
• Voltage 8.4 VDC (6 to 17 VDC)
• Overload Current Protection 800 mA
• Dimensions Not specified by manufacturer
• Weight Stabilizer: 12.9 oz (365 g) (without smartphone or batteries)
• Heavy Counterweight: 1.8 oz (52 g)
• Light Counterweight: 0.2 oz (6 g)
Box Content
• 4 x 900mAh 18350-Type Batteries
• Charger
• USB Cable
• USB Connector
• Heavy Counterweight
• Light Counterweight
• Limited 1-Year Warranty
